INSTRUCTIONS

Step 1: Insert Case Guide into the die body

Step 2: Screw the pin into the shaft about half-way. Use threadlocker on the threads. This will prevent the pin from backing out of the shaft, which can cause problems. Use a 3/16" wrench to hold the flats of the shaft and snug the pin into place. Vice shaft with rubber grips to prevent scarring of the shaft. Do not overtighten the pin into the shaft – just snug it. The threadlockerE will do the rest.

Step 3: Drop the shaft and pin into the die threaded insert. Insert the long spring over the shaft. Screw the shaft and threaded insert into the die body.

Step 4: Place the shaft expander on top of the shaft. Place the spring on top. Screw the cap into place and tighten.

Step 5: Screw the die into your press.

Step 6: Raise the die and bring your tool head all the way down. Turn the die down to touch the shell plate. Then back it out about a 1/2 turn.

Step 7: Decap a case. When you hear the primer flick out you know you’re ready to go.

Optional: If you have the decapping sensor, set the housing on the top of the die by sliding it down until it stops.

If it’s a plug-in sensor, plug the sensor connector into the module. All set to go! When you run into a bad case, the sensor will shut down your drive and save you time and pins.
